Agency Approvals: UL1449, 2nd Edition Feb. 2007 (AC) UL497A (Telco)
Service Voltage: 110-120VAC
MCOV: 125VAC
MCOV – Telco: 130VAC
Connection: Direct plug-in (AC); RJ11 (Telco)
Continuous Current: 15 Amps
Max Surge Current: 39,000 Amps (AC) 5,000 Amps (Telco)
Protection Modes: L-G, L-N, N-G (AC) Tip-G, Tip-Ring, Ring-G (Telco)
U.L. 1449 SVR: 330V
Dimensions: 10.5” x 3.9” x 1.4”
Weight: 1.3lb
Housing: ABS
|
